Pressure Gauge

ISEN Low Pressure Diaphragm Gauge is a mechanical pressure measuring instrument designed for applications where accurate measurement of relatively low pressure is required. Instead of using a conventional Bourdon tube, the gauge uses a single beryllium-copper diaphragm to detect pressure changes and convert them into pointer movement on an analog dial. The gauge features a 2½-inch dial, black-finished drawn steel case, polycarbonate lens, aluminum dial, brass movement, and brass socket. Its specified accuracy is ±1.5% of full scale, exceeding ASME B40.100 Grade B requirements.

• Durable Construction:
  • Case: Crafted from 304 Stainless steel for excellent corrosion resistance.
  • Ring: Features a stainless steel internal rotation ring.
  • Lens: Equipped with tempered glass, with an optional safety glass upgrade available.
  • Dial: Aluminum with a white finish and clear black markings for easy readability.
  • Pointer: Black aluminum and adjustable for precise calibration.
  • Movement: Utilizes durable stainless steel components.
  • Tube & Socket: Constructed from 316L Stainless steel, offering superior corrosion resistance for wetted parts.
• Versatile Connection Options: Available with either 1/2′′ NPT or 1/4′′ NPT connections to suit various installation requirements.
• High Accuracy: Delivers an accuracy of ±1% Full Scale, adhering to ASME B40.100 Grade 1A standards, ensuring reliable measurements for your Utility Pressure Gauge applications.
• Wide Operating Temperature Ranges

• Dual functionality: Displays pressure readings and acts as a switch at preset thresholds for automated control.
• Enhanced safety: Provides immediate response to overpressure or under-pressure conditions.
• Reliable construction: Clear, easy-to-read dial with bar measurements for precise monitoring.
• Process optimization: Maintains pressure within desired limits for stable operations.
• Diaphragm seal option: Protects the sensor when dealing with corrosive or crystallizing media.
• Versatile applications: Suitable for industrial sectors like manufacturing, hydraulics, and pneumatics.

• Case: Stainless steel, weather-tight
• Lens/Dial: Polycarbonate lens, aluminum dial
• Tube/Pointer: SS spiral bourdon tube, yellow-painted SS pointer
• Connection: Brass/SS, 1/8″ or 1/4″ NPT (back outlet)
• Accuracy: ±3.5% (center 60% of scale)
• Process Temp: -40 ~ 200°F (-40 ~ 93°C)
• Ambient Temp: -40 ~ 140°F (-40 ~ 60°C)
• Certification: UL 299 listed

• Accuracy: ±1% (ASME B40.100 Grade 1A)
• Connection: 1/2″ NPT, 1/4″ NPT
• Process Temp (Dry): -40 ~ 250°F (-40 ~ 120°C)
• Process Temp (Filled): 0 ~ 140°F (-18 ~ 60°C)
• Ambient Temp (Dry): -40 ~ 140°F (-40 ~ 60°C)
• Ambient Temp (Filled): 0 ~ 140°F (-18 ~ 60°C)
• Dial Size: 4″ (≈3.94″)

• Remote Monitoring Capability: The core design allows for the pressure sensing point to be separated from the display, connected via a capillary tube, as suggested by the product imagery.
• Clear Visual Indication: The gauge face is designed for unambiguous readings.
• Robust Construction: Built to withstand industrial environments, ensuring longevity and consistent performance.
• Versatile Sizing: The ISEN model is available in 1" and 1.4" sizes, providing options for different installation requirements.
