Specification Value Model VMCS-728A Product Type Automatic Drain Valve Orifice Size 3.5 mm Operation Normally Closed (NC) Power Supply AC/DC 24–240 V ±10% Power Consumption AC 22 VA / DC 20 W Working Pressure 0–16 bar Working Temperature 0°C–80°C Body Material Brass Seal Material NBR / VITON -
- Connection Type: Flange
- Size Range: DN50 to DN500
- Working Pressure: PN16 (≈ 200 PSI)
-
Main Materials:
-
Body: Ductile Iron (DI)
-
Bonnet: Ductile Iron (DI)
-
Screen: Stainless Steel 304 (SS304)
-
-
- Direct-acting design with a simple and reliable structure.
- No external power supply or control air required.
- Maintains stable downstream pressure.
- Fast response to changes in system demand.
- Suitable for low-pressure steam and compressed air systems.
- Reduces energy loss in steam distribution systems.
- Easy to install and maintain.
Specification Value Model VYT-1000L Product Type Electro-Pneumatic Positioner Suitable Valve Globe Valve Control Signal 4–20 mA Signal Input 4–20 mA Signal Output 4–20 mA Supply Pressure 1.4–7 bar (20–100 psi) Air Connection G1/4″ Protection Rating IP66 Ambient Temperature -20°C to 70°C - Automatic condensate discharge without manual operation.
- Mechanical float and lever operating mechanism.
- No electrical power or external control required.
- Compact ball-type design for space-saving installation.
- Direct threaded installation on the pipeline.
- Reliable operation with minimal maintenance.
- Suitable for industrial condensate drainage applications.
- Body and Bonnet: Available in Carbon steel or stainless steel.
- Seat: Constructed from Stainless steel.
- Internal Parts: Made from Stainless steel.
Key Features
- Valve position indicator allows easy monitoring of the open/closed status.
- Easy to install.
- Wear-resistant piston design provides high flow capacity with low pressure loss.
- Internal components are factory-lubricated, minimizing routine maintenance requirements.
- Actuator components are constructed from stainless steel and aluminum.
- Long service life piston rod combined with PTFE seals for enhanced sealing performance.
- Water hammer resistant design.
- Reliable sealing performance.
Model: VMIBSW16-050 WAFER TYPE BUTTERFLY VALVE Size: DN50(2â²) Connection: wafer Pressure rating: PN16 Body: SS304 Disc: SS304 Shaft: SS416 Seat: PTFE Handlever Operated (Van bÆ°á»m tay gạt inox DN50 PN16) + Model: VAX03 Power supply: AC220V 50/60Hz Drive apdater: 11 mm Output torque: 40Nm
'- Size: DN65(/2 1/2'') -Type 2 pieces - Connection: Flanged PN16 - Ball: SS304 - Body: Steel WCB - Gasket: PTFE - Temp.max: 180*C Included: Pneumatic Actuator type double acting
Model: VQ641F-16C Pneumatic Carbon steel Control ball valve with flanged – Size: DN65(/2 1/2”) -Type 2 pieces – Connection: Flanged PN16 – Ball: SS304 – Body: Steel WCB – Gasket: PTFE – Temp.max: 180*C + Model: VAX10 VMAL Electric Actuator Power supply: AC220V 50/60Hz Drive apdater: 14/17 mm Output torque: 100Nm
Specification Value Model VQ611F-16P3 Valve Type 3-Piece Pneumatic Ball Valve Size DN32 (1-1/4″) Connection Female Thread Body Material SS304 Stainless Steel Ball Material SS304 Stainless Steel Seat Material PTFE Maximum Working Temperature 180°C Actuator Type Double-Acting Pneumatic Actuator - Working Pressure: Up to 160 Bar
- Glass Dimensions (mm):
- Length: 85 – 500 mm
- Width: 30 – 34 mm
- Thickness: 16.8 – 22 mm
- Center-to-Center Distance (C-C): 235 – 3600 mm
- Visible Length: 90 – 3360 mm
- Flange Connection Sizes (DN): DN15, DN20, DN25, DN40, DN50
- View Angle (ISEN-B49H-1.6): 200°
- View Distance (ISEN-B49H-1.6): <60 m
