Specification Value Model VYT-1000L Product Type Electro-Pneumatic Positioner Suitable Valve Globe Valve Control Signal 4–20 mA Signal Input 4–20 mA Signal Output 4–20 mA Supply Pressure 1.4–7 bar (20–100 psi) Air Connection G1/4″ Protection Rating IP66 Ambient Temperature -20°C to 70°C Specification Value Model VMRMF-45DD Valve Type Right Angle Solenoid Pulse Valve Port Size Ø50 Body Material Aluminum Working Pressure 0.3–0.8 MPa Ambient Temperature -5°C to +55°C Relative Humidity < 85% Working Media Clean Air Power Supply 220 V Connection Type Insert Pipe Type Specification Value Model VMRMF-Z-25P Valve Type Right Angle Solenoid Pulse Valve Size DN25 (1″) Working Pressure 0.3–0.8 MPa Ambient Temperature -5°C to +55°C Relative Humidity < 85% Working Medium Clean Air Power Supply 220 VAC Connection G1″ Thread Specification Value Model VMRMF-Z-35P Valve Type Right Angle Solenoid Pulse Valve Size DN40 (1-1/2″) Working Pressure 0.3–0.8 MPa Ambient Temperature -5°C to +55°C Relative Humidity < 85% Working Medium Clean Air Power Supply 220 VAC Connection G1-1/2″ Thread Model: VMSB116-41315 Solenoid valve type normal closed max operating temp: 180degC max operating pressure: 16 barg material: Brass size: DN15 (1/2”) Connection: Thread G 1/2” power supply: 220vac/50hz
DIN Bellow Globe Valve
-
Design Standard: DIN 3356
-
Face-to-Face Dimension: DIN 3202
-
Flanged Ends: DIN 2543–2545
-
Test & Inspection: DIN 3230
ANSI Bellow Globe Valve
-
Design Standard: ASME B16.34
-
Face-to-Face Dimension: ASME B16.10
-
Flanged Ends: ASME B16.5
-
Test & Inspection: API 598
-
